EURORACK MX602A

1. INTRODUCTION

Congratulations. In purchasing our EURORACK MX602A you have acquired a mixer whose small size belies

its incredible versatility and superlative audio performance. Your EURORACK is built to the same outstanding

quality as our top-of-the line console, the BEHRINGER EURODESK MX9000.

We recommend that you experiment with your EURORACK away from the pressures of a recording session or

live concert, in order to get a feel for it. It is a musical instrument. Learn to play it well.

Next to the specifications in the appendix you will find some pages with drawings showing the front and rear panel

of your EURORACK. Keep them turned over, lying to the left of the text pages, while studying the manual. All

functions will be numbered consistently throughout the manual, whether they be in the text or on an illustration.

2. EURORACK OVERVIEW

2.1 Architecture

Mono input channels

Channels 1 and 2 are mono, with a choice of balanced mic or line inputs. The vintage-style high-current

discrete mic amps are of the same incredible quality as those found on the acclaimed BEHRINGER EURODESK

MX9000, while a large external power supply ensures low noise and superior transient response at all times.

Stereo input channels

A further 4 line inputs are configured as 2 stereo input channels. These are ideal for accepting outputs from

MIDI and other electronic instruments.

Channel outputs

A high-quality rotary potentiometer feeds the main mix via a constant-power channel pan potentiometer.

Aux send

There is one aux send bus on the MX602A, set post-fader (the channel’s volume control).

Stereo line inputs

There is a line-level stereo aux return at the top of the output section. It can be used to return stereo effects or

MIDI instruments etc.

In addition, a stereo tape input is provided, which may also be routed to the main mix, giving the MX602A a total

of 10 possible inputs during mixing. Channels 1 and 2 on the MX602A have overload LEDs, while the main mix

output has 4-segment bargraph meters.

2.2 Packing & warranty

Please take time to have the warranty card filled out completely and return it within 14 days after the date of

purchase, so as to be entitled to benefit from our extended warranty. You can find the serial number on the

rear panel of your MX602A. Or use our online registration option available on the Internet at www.behringer.com.

Your BEHRINGER MX602A was carefully packed in the factory and the packaging was designed to protect the

unit from rough handling. Nevertheless, we recommend that you carefully examine the packaging and its

contents for any signs of physical damage, which may have occurred in transit. See chapter 7 for details.

 If the unit is damaged, please do not return it to us, but notify your dealer and the shipping

company immediately, otherwise claims for damage or replacement may not be granted.

2.3 PSU (power supply unit)

Any amplifier circuit is limited in its transient response by the available current. Every mixer has numerous line

level operational amplifiers (op-amps) inside. When being driven hard, many desks begin to show signs of

stress due to power supply limitations. Not so with the EURORACK. The sound will always stay clean and

crisp right up to the operating limits of the op-amps themselves, thanks to the generous 10 W external power

supply unit.

 Connect only the provided BEHRINGER power supply unit to the MX602A via the AC POWER IN

connector . Do not connect the PSU to the EURORACK while the PSU is connected to the

mains supply. The correct starting sequence is: connect mixer and PSU and then connect the

PSU to the mains.
